Both motors feature a 1.8° step angle design, offering stable stepping accuracy, making them suitable for various automation control and precision motion systems.
| LC11D-06A10 | |
| 体长 | 31.1mm |
| 额定电压（Vm）直流 | 2.7 |
| 安培/相 | 1 |
| 电阻/相位Rm（欧姆） | 2.7 |
| 电感/相位（MH@1000Hz） | 2.4 |
| 最小保持扭矩（N-cm） | 6 |
| 步进角（度） | 1.8 |
| 步进精度（非累加）% | ±5 |
| LC11D-12A10 | |
| 体长 | 44.4mm |
| 额定电压（Vm）直流 | 3.2 |
| 安培/相 | 1 |
| 电阻/相位Rm（欧姆） | 3.2 |
| 电感/相位（MH@1000Hz） | 4 |
| 最小保持扭矩（N-cm） | 12 |
| 步进角（度） | 1.8 |
| 步进精度（非累加）% | ±5 |
